1, the scope of application:
Widely used in water, environmental monitoring, health and epidemic prevention, quality inspection, petrochemical, geological exploration, pharmaceutical production inspection and other fields.
2, the instrument work environment:
3, performance indicators:
(1) Inorganic Anion Detection Type: One injection Simultaneous detection of F-, Cl-, NO2-, PO43-, Br-, SO42-, NO3-, ClO2-, BrO3-, ClO3- etc.
Cationic: simultaneous detection of Li +, Na +, NH4 +, K +, Ca2 +, Mg2 +, Sr2 +, Ba2 + etc.
(2) with built-in pool pillar integrated thermostat system (to provide relevant technical documents).
(3) independent operation, you can no PC with, 5.7-inch true color touch LCD screen, display more delicate, more convenient operation. With the drag and drop function of the software, you can view any details of the spectrum.
(4) data dual backup, more stable and reliable, using cloud storage technology, data to download anytime, anywhere
(5) to achieve conductivity detector, injection valve, high pressure advection pump, workstations, thermostats and other components of the integration, if equipped with cationic separation column can be completed on time and anion analysis, the user can choose according to their own needs.
* (6) powerful data post-processing capacity, with the PAS series of autosampler with, to complete the linear calibration and sample automatic analysis.
* (7) with the Pixon instrument ion chromatography mobile phone software to match the remote control of equipment and access to data. Through the mobile phone software can always view the operation of equipment, and retrieve the relevant spectrum and data.
(8) can now support dual-channel conductivity detector + single-channel voltammetry detector; can support single-channel conductivity detector, voltammetry detector, UV detector; according to user requirements, can be any combination.
4, conductivity detector:
5, high pressure advection pump:
The machine is a microprocessor-controlled dual-piston reciprocating pump, the use of advanced intelligent control algorithm, can make the pump flow pulsation to a minimum level.
6, the flow system:
The flow system uses PEEK material (imported parts), good versatility, can use strong acid, alkali eluent, and can be compatible with organic solvents, user-friendly analysis of complex samples, washing and maintenance. The user can replace the column and eluent. To avoid the pain of the flow of the pain, so that users no worries.
7, suppressor:
Continuous automatic regenerative electrochemical microfilm suppressor, on-line automatic regeneration, high suppression capacity, low background conductance, low noise, baseline stability, maintenance-free. Anti-pollution, good pressure, long life, the use of a wide range (PH0-14). Small size, stable time, and good reproducibility.
8, chromatography workstation:
24-bit high-precision high-sensitivity digital-to-analog conversion. Dedicated ion chromatography workstation, through high-performance USB way with the computer for digital signal transmission, complete the cation and cation data acquisition and processing. Can achieve the instrument anti-control operation, through the computer online set the instrument operating parameters, man-machine dialogue. Automatically receive analysis and control to save instrument chromatographic conditions. Automatic recognition of negative peak, baseline subtraction function. Automatic integration of parameters, automatically generate reports. Automatically detect the instrument running status, the operation of the fault alarm and the instrument to provide protection measures.
* 9, test technical indicators: (JJG823-2014 "ion chromatograph measurement test procedures" shall prevail, and provide the procedures issued by the type of evaluation report and measurement equipment license and measurement equipment type approval certificate)
* 10. Autosampler
Shall provide proof of the appearance of the autosampler, the lifting device, the needle clamp, the syringe carriage, and the base turntable.
Using the electric injection valve full tube injection method, can directly trace sample injection and rapid analysis, can effectively solve the sample residue, injection rate and sample reproducibility and other issues.
Note: Due to technical progress update, the performance indicators will improve, site indicators for reference only.
